Wheel Loader ZL80H

Get a Quote

Data download

Get a Quote

Data download

Powerful engine-equipped with reliable XIAN CUMMINS engine, high horsepower, can meet the needs of operation
Excellent operation design-KD switch design,improve operation efficiency, more convenient operation
Excellent built-in system-reliable ZF gearbox and torque converter to ensure stable and efficient power transmission;Well-known original ZF wet bridge, with multi-plate limited slip differential, provides excellent traction; Combined sealed cylinder, high sealing performance, more reliable; double brake valve and double pipeline full hydraulic brake system to ensure safe and efficient braking.
Powerful operation capacity and rich application scenarios-with bucket automatic leveling function to achieve precise leveling operation
Powerful safety and security-double brake valve and double pipeline full hydraulic brake system to ensure safe and efficient braking;Centralized lubrication system to extend component life and make maintenance more convenient.

Parameter

Dimensions	Overall length (bucket on the ground)	8696mm
	Overall width(outside of wheels)	3099mm
	Bucket width	3250mm
	Overall height	3710mm
	Wheel base	3400mm
	Min. ground clearance	504mm
Specification	Rated load	7500kg
	Rated bucket capacity	4.2m³
	Operating weight	27500kg
	Min. turning radius(outside of the tyre)	6486mm
	Turning angle of the chassis	38º
Performance	Travelling speed	Forward&Reverse：7.8/12.4/25.9/37km/h
	Max. tractive force	222kN
	Dumping angle	45º
	Dumping clearance	3220mm
	Dumping reach	1275mm
	Total cycling time	≤12s
Engine	Model	Cummins
	Type	Direct injection. Turbocharged. Air to air cooling
	Rated power	216Kw
	Max. torque	1478(N.m) 2100(r/min.)
