| Dimension | Length(with bucket on ground) | 3700(mm) |
| Width(to outside of wheels) | 2030(mm) | |
| Bucket width | 2050(mm) | |
| Height(To the top of the cab) | 2160(mm) | |
| Wheel base | 1500(mm) | |
| Tread | 1654(mm) | |
| Min. ground clearance | 205(mm) | |
| Performance | Rated load | 1200(Kg) |
| Operating weight | 4500KG | |
| Rated bucket capacity | 0.6(m3) | |
| Max. breakout force | 30kN | |
| Static tipping loads | 24kN | |
| Max. dump clearance | 2550(mm) | |
| Dump reach | 700(mm) | |
| Engine | Model | WEICHAI |
| Type | Direct injection. Turbocharged. Water cooling | |
| Emission | Tier Ⅱ | |
| Displacement | 4.1 | |
| Rated power | 74.9KW@2400rpm |
