Motor Grader PY150

Inquiry

Efficient and Durable Components -- Key components, including pumps, motors, and check valves, are sourced from renowned manufacturers. This ensures stable performance, extended service life, and reduced downtime.
Advanced Transmission System -- The machine features a ZF transmission with single-lever electrohydraulic control, offering six forward gears and three reverse gears. It combines hydrodynamic and electrohydraulic power shifting to provide strong tractive force, optimized travel speeds, and enhanced work efficiency.
Excellent Stability -- The grader’s design prioritizes stability through a well-balanced weight distribution. This ensures steady performance on hard surfaces, reduces vibration, improves grading accuracy, and enhances operator comfort and safety.
Outstanding Operability -- Maintenance-free batteries minimize daily upkeep. Key components like relays and fuses are conveniently located in the right-hand control box. The large access panel design facilitates quick maintenance, reducing downtime and ensuring stable operation.
Convenient and Reliable Full-Hydraulic Control -- The full-hydraulic control system provides precise machine control with low flow and minimal energy loss, enhancing fuel economy. Components are easily accessible for maintenance, reducing costs and ensuring efficient operation in various conditions.

Parameter

Basic specification
Engine model	Cummins
Rated power	113KW@2200rpm
Dimension(L×W×H)	8290×2600×3465（mm）
Operating weight(Standard)	12000KG
Performance specification
Travelling speed ,forward	6.9/10.7/17.3/26/37.8/53.4
Travelling speed ,reverse	6.9/17.3/37.8
Tractive force(f=0.75)	61.7KN
Operating specification
Max. steering angle of front wheels	49°
Max. lean angle of front wheels	17°
Max. oscillation angle of front axle	16°
Max. oscillation angle of balance box	13°
Frame articulation angle	26°
Min. turning radius using articulation	6.6m
Blade
Maximum lift above ground	410mm
Maximum grading depth	560mm
Maximum blade position angle	90°
Blade cutting angle	29°~77°
Circle reversing rotation	360°
Moldboard width × height	3658×580x16mm
