Reinforced Structural Design for Durability
The machine’s frame is reinforced for durability, featuring a compact structure, small turning radius, and excellent mobility to handle high-intensity operations with ease.
Comprehensive Safety Features
Includes an emergency brake button and fuel cut-off system to ensure operator and equipment safety during unexpected situations.
Efficient Filtration & Diagnostic Support
A multi-level filtration system ensures clean oil circulation, while pressure diagnostic interfaces simplify maintenance and troubleshooting.
Optimized Cooling System for High-Temperature Environments
Designed with an enhanced heat dissipation system to maintain optimal performance under high-load and high-temperature operating conditions.
Ergonomic Cab for Operator Comfort
Luxurious air-conditioned cab with soundproof and shock-absorbing design, LED lighting, intuitive LCD instrument panel, and user-friendly controls — ensuring comfort, visibility, and ease of operation even during extended use.
Operating weight |
12000 kg |
Vibratory drum diameter |
1430 mm |
Compaction width |
1980 mm |
Static line pressure |
285 N/cm |
Min. ground clearance |
450 mm |
Wheel base |
3000 mm |
Min.turning radius |
6000 mm |
Gradeability |
30% |
Vibratory amplitude |
1.6/0.8 mm |
Vibratory frequency |
30 Hz |
Centrifugal force |
265/125 kN |
Travelling speed |
|
(Forward) |
2.0/4.2/8.7 km/h |
(Reverse) |
2.0/4.2 km/h |
Tyre model |
17.5-25 |
Engine model |
WP4G110E221 or WP4.1G102E301 |
Rated power |
82/2000 or 74.9/2400 kW/rpm |
Rated speed |
2000/2400 r/min |
Dimension |
5570×2180×3010 mm |
