Smart Monitoring System — Equipped with an 8-inch high-resolution, anti-glare color display, the intelligent monitoring system provides real-time diagnostics, maintenance reminders, self-diagnosis of faults, and alarm notifications.
Comfortable & Secure Cab — Designed with safety and comfort in mind, the modern cab features injection-molded interior components, a spacious layout, and fully automatic.
| Dimensions | Operating weight | Kg | 20750 |
| Rated bucket capacity | m3 | 1.0 | |
| Overall length | mm | 9660 | |
| Overall width（Standard track shoe） | mm | 2510 | |
| Overall height | mm | 2800 | |
| Standard track shoe width | mm | 600 | |
|
Performance |
Travelling speed (H/L) | Km/hr | 5.7/3.1 |
| Swing speed | rpm | 11.8 | |
| Gradeability | Degree(%) | 35（70%） | |
| Ground pressure | Kgf/cm2 | 0.47 | |
| Working Range |
Maximum digging radius | mm | 9770 |
| Maximum digging depth | mm | 9610 | |
| Maximum digging height | mm | 9680 | |
| Bucket digging force | kN | 150 | |
| Stick digging force | kN | 105 | |
| Engine | Model | Cummins | |
| Type | 6-cylinder in-line, four-stroke | ||
| Rated power | 112kW（150HP ) @1950rpm | ||
