Bulldozer YD220

Operating Weight : 23500 kg
Power : 175 kw
Overall Dimension : 5390×3735×3350mm

Get a Quote

Data download

Get a Quote

Data download

Powerful Performance and Energy Efficiency — Equipped with Cummins engines, our machines deliver robust power while maintaining high energy efficiency.
Efficient Power Transmission System — Our high-reliability power-shift transmission, stable torque converter, and two-stage straight-tooth final drive all contribute to efficient power transmission.
Intelligent Diagnosis and Integrated Dashboard — Our system supports automatic fault diagnosis and full-process monitoring. The integrated dashboard, which combines air conditioning, electrical systems, and instruments, offers an aesthetically pleasing and high-end appearance.
High Load-bearing Capacity Main Frame — The fully boxed main frame, constructed from steel plate welding into a fully boxed integral structure and welded to the rear axle box, provides high capacity for bearing impact loads and resisting bending and torsion. High-quality welds ensure the main frame has a full life cycle.
Semi-rigid Suspension Travel System — The semi-rigid suspension travel system increases the ground contact area of the track, enhancing the vehicle's tractive force.
Ergonomic Operation Design — Designed in accordance with ergonomics, the driver's seat and armrests can be adjusted vertically and horizontally. The speed change, steering, and throttle controls are located on the left side, utilizing a flexible shaft structure. The working device controls are on the right side, featuring a servo control system. This design makes the operation process more lightweight, flexible, and less tiring.
Powerful Working Equipment Configuration — The standard straight-tilt dozer blade offers strong cutting force. The large single-tooth or three-tooth ripper features an adjustable angle of entry into the soil, suitable for loosening soil layers such as clay and hardened frozen soil, as well as stripping harder working surfaces like gravel and compacted salt mines.

Parameter

Model	GTY220
Type	Standard Hydraulic Crawler Type
Model	CUMMINS
Displacement	14.01L
Rated power	175/1800 kw/rpm
Max.torque	1085/1300 N.m/rpm
Operating weight	23.5T
Dimension(no ripper)	5390×3735×3350mm
Ground length	2730mm
Ground pressure	0.077 MPa
Track gauge	2000mm
Dozing capacity	6.4m³
Blade width	3735 mm
Blade height	1317mm
Max drop below ground	735mm
Track shoe width	560mm
Pitch	216mm
Quantity of track link	38
Quantity of Carrier rollers	4
Quantity of Track rollers	12（8 Double+4 Single）
Max pressure	14 MPa
Discharge	262 L/min
Max tractor force	203KN
Grade ability	30°
Forward Speed (Km/h)	F1:0-3.6
	F2:0-6.5
	F3:0-11.2
Rear Speed (Km/h)	R1:0-4.3
	R2:0-7.7
	R3:0-13.2
